Product Advantage
1. High-Power Hydraulic Configuration
With a recommended power of 30 kW, this model provides stronger hydraulic output than many standard supplier products, ensuring stable lifting under heavy loads.
2. Enhanced Structural Stability
The reinforced structure and increased self-weight improve overall rigidity, reducing vibration and improving operational safety compared with conventional designs.
3. Wide 400° Slewing Angle
Allows flexible and efficient material handling without frequent truck repositioning, especially beneficial in complex industrial environments.
4. Consistent Performance Under Heavy Load
The optimized hydraulic system maintains smooth movement and precise control even during continuous heavy-duty operation.
5. Manufacturer-Level Quality Assurance
Produced by Tengchang Construction Machinery, ensuring reliable quality, traceability, and long-term service support.
|
Technical Parameters
Crane main technical parameters
Maximun lifting weight | 6300Kg | Oil tank capacity | 100L |
Max lifting movement. | 12.6 t.m | Slewing angle | 360° |
Recommended power | 30KW | Hydraulic crane weight | 2300kg |
Recommended hydraulic flow | 40 L/min | Installation space | 1050mm |
Rated hydraulic pressure | 28MPa | Slewing pressure | ≤20MPa |
|
Product Uses
1. Heavy Industrial Lifting
Used in factories, steel plants, and industrial zones for lifting large components, machinery, and production equipment.
2. Infrastructure and Civil Engineering
Ideal for bridge construction, road projects, and public infrastructure where heavy lifting capacity and stability are required.
3. Logistics and Fleet Operations
Suitable for transport companies handling heavy cargo and requiring dependable equipment with low downtime.
4. Energy and Utility Projects
Applied in power generation, substations, and utility installations demanding precise and powerful lifting solutions.
|
FAQ
1. Why is this crane more stable than typical supplier products?
A: Tengchang cranes use reinforced booms, optimized load distribution, and higher manufacturing standards, resulting in superior stability.
2. Is the hydraulic system more durable?
A: Yes, the system is designed to reduce pressure loss and heat buildup, improving longevity compared to many market alternatives.
3. Can it handle high-frequency daily operation?
A: Yes, it is engineered specifically for continuous and intensive working conditions.
4. Does Tengchang support customization?
A: Yes, configuration and functional customization are available.
